Electrolyzer Hydrogen Generator – Hydrolite
Electrolyzer Hydrogen Generator, Hydrolite
Hydrolite Electrolyzer Hydrogen Generator – eHG – is a low-cost, high-simplicity electronic hydrogen generator. Input only water and power – from your renewable generator or provider for certified Green Hydrogen – and generate hydrogen fuel for the Hydrolite Full Cell System – FCS, or for any other hydrogen applications.
Low up-front costs, operations expenses
Hydrolite’s advanced AEM (Anion exchange membrane) technology provides a high performance device with very low capital expenditure, while maintaining the generation efficiency of more expensive technologies. The combination of aqueous alkaline conditions and exchange membrane technology gives the lowest up-front costs combined with the highest available electrical performance.
Minimizes Critical Raw Materials usage
Hydrogen as zero-carbon energy is attractive primarily because of the combination of flexibility of deployment and low materials usage, whereas every additional unit of battery storage demands additional critical materials to facilitate that storage. Hydrolite’s advanced electrolysis technology combines high efficiency and performance with minimal critical material use, so that with renewable power sourcing, Hydrolite’s Electrolyzer Hydrogen Generator- eHG provides certifiable Green Hydrogen at the lowest cost per kg, but also at highest scalability.
Electrolyzer Hydrogen Generator- for Green H2 Production
High Performance
-45 KWh to produce
1 kg of H2
H2, quality – 99.999%
Low Capex
-$500 per KW
Production Cost of H2
-$1.22 per kg ex. electricity costs
Water Quality
Low Requirements
(tap, brine)
Unlike PEM which requies
deionized water
Lifetime
10 Years
Sustainability
Quiet, no emissions, 95% recyclable
Minimal water quality requirements
Hydrolite’s Electrolyzer Hydrogen Generator systems can run on regular tap water with no need for deionization further adding to operational convenience, flexibility and scalability.
Technical info Electrolyzer Hydrogen Generator
Generation 1 Hydrolite Electrolyzer Hydrogen Generator – eHG
| Nominal system size (Power Output)* | 10-50kW |
| Peak efficiency | 42-45 kWh/kg H2 |
| Output hydrogen purity | 99.999% |
| Water purity | Conductivity |
